台湾ME-3 聚氨酯铁壳防尘密封
材料：M-90 最大工作压力：40MPA
速度：0.03~0.5M/sec
油缸往复用，骨架/反向唇口防尘密封圈，温度-35℃~100℃。
特点：轴用、有防尘副唇、起到保压作用和作二次密封作用。
| 品名 | d | D | t | h | H |
| ME-3 | 6.3 | 16 | 5 | 7 | 5 |
| ME-3 | 10 | 20 | 5 | 7 | 5 |
| ME-3 | 11.2 | 21 | 5 | 7 | 5 |
| ME-3 | 12.5 | 23 | 5 | 7 | 5 |
| ME-3 | 14 | 24 | 5 | 7 | 5 |
| ME-3 | 15 | 25 | 5 | 7 | 5 |
| ME-3 | 16 | 26 | 5 | 7 | 5 |
| ME-3 | 18 | 28 | 7 | 10 | 7 |
| ME-3 | 18 | 30 | 6 | 9 | 6 |
| ME-3 | 20 | 30 | 5 | 7 | 5 |
| ME-3 | 20 | 32 | 6 | 9 | 6 |
| ME-3 | 22.4 | 34.4 | 6 | 9 | 6 |
| ME-3 | 25 | 37 | 6 | 9 | 6 |
| ME-3 | 27 | 39 | 6 | 9 | 6 |
| ME-3 | 28 | 40 | 6 | 9 | 6 |
| ME-3 | 30 | 40 | 5 | 7 | 5 |
| ME-3 | 30 | 42 | 6 | 9 | 6 |
| ME-3 | 30 | 45 | 7 | 10 | 7 |
| ME-3 | 31.5 | 44 | 7 | 10 | 7 |
| ME-3 | 31.75 | 41.28 | 4.75 | 7.14 | 4.75 |
| ME-3 | 32 | 44 | 7 | 10 | 7 |
| ME-3 | 35 | 47 | 7 | 10 | 7 |
| ME-3 | 35.5 | 47.5 | 7 | 10 | 7 |
| ME-3 | 38 | 50 | 7 | 10 | 7 |
| ME-3 | 38.1 | 47.63 | 4.75 | 7.14 | 4.75 |
| ME-3 | 40 | 52 | 7 | 10 | 7 |
| ME-3 | 45 | 57 | 7 | 10 | 7 |
| ME-3 | 50 | 60 | 7 | 10 | 7 |
| ME-3 | 50 | 62 | 7 | 10 | 7 |
| ME-3 | 53 | 67 | 8 | 11 | 8 |
| ME-3 | 55 | 69 | 8 | 11 | 8 |
| ME-3 | 56 | 70 | 8 | 11 | 8 |
| ME-3 | 60 | 74 | 8 | 11 | 8 |
| ME-3 | 63 | 77 | 8 | 11 | 8 |
| ME-3 | 64 | 78 | 8 | 11 | 8 |
| ME-3 | 65 | 79 | 8 | 11 | 8 |
| ME-3 | 67 | 81 | 8 | 11 | 8 |
| ME-3 | 70 | 84 | 8 | 11 | 8 |
| ME-3 | 71 | 85 | 8 | 11 | 8 |
| ME-3 | 75 | 89 | 8 | 11 | 8 |
| ME-3 | 76.2 | 85.72 | 4.75 | 7.14 | 4.75 |
| ME-3 | 80 | 94 | 8 | 11 | 8 |
| ME-3 | 85 | 99 | 8 | 11 | 8 |
| ME-3 | 90 | 104 | 8 | 11 | 8 |
| ME-3 | 95 | 109 | 8 | 11 | 8 |
| ME-3 | 100 | 114 | 8 | 11 | 8 |
| ME-3 | 105 | 121 | 9 | 12 | 9 |
| ME-3 | 110 | 126 | 9 | 12 | 9 |
| ME-3 | 115 | 131 | 9 | 12 | 9 |
| ME-3 | 120 | 136 | 9 | 12 | 9 |
| ME-3 | 125 | 140 | 9 | 12 | 9 |
| ME-3 | 125 | 141 | 9 | 12 | 9 |
| ME-3 | 140 | 160 | 10 | 14 | 10 |
| ME-3 | 150 | 170 | 10 | 14 | 10 |
| ME-3 | 160 | 180 | 10 | 14 | 10 |
| ME-3 | 170 | 190 | 10 | 14 | 10 |
| ME-3 | 175 | 195 | 10 | 14 | 10 |
| ME-3 | 180 | 205 | 12 | 17 | 12 |
