| 孔用组合密封圈（格来圈） | |||
| 内径d 外径D 厚度B | 内径d 外径D 厚度B | 内径d 外径D 厚度B | 内径d 外径D 厚度B |
| 20*15*2.2 | 50*39*4.2 | 85*69.5*6.3 | 170*149*8.1 |
| 20*12.5*3.2 | 50*34.5*6.3 | 90*79*4.2 | 175*154*8.1 |
| 24*19*2.2 | 52*41*4.2 | 90*74.5*6.3 | 180*159*8.1 |
| 24*16.5*3.2 | 52*36.5*6.3 | 95*84*4.2 | 190*169*8.1 |
| 25*17.5*3.2 | 55*44*4.2 | 95*79.5*6.3 | 200*179*8.1 |
| 25*14*4.2 | 55*39.5*6.3 | 100*89*4.2 | 210*189*8.1 |
| 28*20.5*3.2 | 56*45*4.2 | 100*84.5*6.3 | 220*199*8.1 |
| 28*17*4.2 | 56*40.5*4.2 | 105*94*4.2 | 230*209*8.1 |
| 30*22.5*3.2 | 56*40.5*6.3 | 105*89.5*6.3 | 240*219*8.1 |
| 30*19*4.2 | 60*49*4.2 | 110*99*4.2 | 250*229*8.1 |
| 32*24.5*3.2 | 60*44.5*6.3 | 115*99.5*6.3 | 260*239*8.1 |
| 32*21*4.2 | 63*52*4.2 | 120*104.5*6.3 | 270*249*8.1 |
| 35*27.5*3.2 | 63*47.5*6.3 | 125*109.5*6.3 | 275*254*8.1 |
| 35*24*4.2 | 64*53*4.2 | 125*104*8.1 | 280*259*8.1 |
| 36*28.5*3.2 | 64*48.5*6.3 | 130*114.5*6.3 | 290*269*8.1 |
| 36*25*4.2 | 65*54*4.2 | 130*109*8.1 | 300*279*8.1 |
| 38*30.5*3.2 | 65*49.5*6.3 | 135*119.5*6.3 | 310*289*8.1 |
| 38*27*4.2 | 70*59*4.2 | 140*124.5*6.3 | 320*299*8.1 |
| 40*32.5*3.2 | 70*54.5*6.3 | 140*119*8.1 | 330*305.5*8.1 |
| 40*29*4.2 | 75*64*4.2 | 145*124*8.1 | 340*315.5*8.1 |
| 45*37.5*3.2 | 75*59.5*6.3 | 150*129*8.1 | 350*325.5*8.1 |
| 45*34*4.2 | 80*69*4.2 | 155*134*8.1 | |
| 48*40.5*3.2 | 80*64.5*6.3 | 160*139*8.1 | |
| 48*37*4.2 | 85*74*4.2 | 165*144*8.1 | |
